SB Acoustics Satori WO24TX-8

€389.00 *

Prices incl. VAT plus shipping costs

Delivery time 1-3 Workdays

  • 1382543
SB Acoustics Satori WO24TX-8 Advanced TeXtreme® cone for improved piston operation Large... more
Product information "SB Acoustics Satori WO24TX-8"

SB Acoustics Satori WO24TX-8

  • Advanced TeXtreme® cone for improved piston operation
  • Large optimized motor system with under-cut pole piece and dual shorting rings
  • Vented aerodynamic cast aluminum chassis for optimum strength and low compression.
  • Soft low damping rubber surround for optimum transient response
  • Linear symmetric suspension design for improved dynamic performance
  • Non-conducting fibre glass voice coil former for minimum damping
  • Long life silver lead wires attached 180° apart for improved stability
  • Vented pole piece for reduced compression
  • Low piston to chassis diameter ratio
  • Gasket and bolt hole protrusions for reduced coupling to speaker cabinet.



  • Nominal Impedance 8 Ω
  • DC resistance, Re 5.8 Ω
  • Voice coil inductance, Le 0.56 mH
  • Effective piston area, Sd 255 cm2
  • Voice coil diameter 49.5 mm
  • Voice coil height 23.1 mm
  • Air gap height 6 mm
  • Linear coil travel (p-p) 17.1 mm
  • Magnetic flux density 1.12 T
  • Magnet weight 1.36 kg
  • Net weight 3.9 kg
  • Free air resonance, Fs 24.5 Hz
  • Sensitivity (2.83V/1m) 88 dB
  • Mechanical Q-factor, Qms 5.67
  • Electrical Q-factor, Qes 0.36
  • Total Q-factor, Qts 0.34
  • Moving mass incl. air,Mms 44.2 g
  • Force factor, Bl 10.45 Tm
  • Equivalent volume, Vas 88 liters
  • Compliance, Cms 0.95 mm/N
  • Mechanical loss, Rms 1.2 kg/s
  • Rated power handling* 90 W
