Wavecor WF152BD06 Paper/Glass Fiber 8 Ohm The 6” transducers WF152BD05 (4 ohm)... more
Product information "Wavecor WF152BD06"
Wavecor WF152BD06 Paper/Glass Fiber 8 Ohm
The 6” transducers WF152BD05 (4 ohm) and WF152BD06 (8 ohm) were designed as high performance bass and midrange units for very compact monitors and high-end hi-fi speakers.
FEATURES
- Balanced Drive motor structure for optimal drive force symmetry resulting in largely reduced even order harmonic distortion
- Copper cap on center pole to reduce voice coil inductance and to minimize variations in voice coil inductance as a function of voice coil position
- Cone made of a new paper/glass fiber mix with improved consistency and stability
- Rigid die cast alu chassis with extensive venting for lower air flow speed reducing audible distortion
- Vented voice coil former for reduced distortion and compression
- Vented center pole with dual flares for reduced noise level at large cone excursions
- Heavy-duty black fiber glass voice coil former to reduce mechanical losses resulting in better dynamic performance and low-level details
- Large motor with 1¼” voice coil diameter for better control and power handling
- Built-in alu field-stabilizing ring for reduced distortion at high levels
- Low-loss suspension (high Qm) for better reproduction of details and dynamics
- Black motor parts for better heat transfer to the surrounding air
- Conex spider for better durability under extreme conditions
- Gold plated terminals to ensure long-term trouble free connection
SPECIFICATIONS
- power handling (continuous/programme) = 70 W
- frequency range = 50-3500 Hz
- resonance frequency fs = 46 Hz
- impedance R = 8 Ohm
- sound pressure level SPL = 87 dB (2,83V; 1m)
- DC resistance Re = 6,3 Ohm
- force factor BL = 8 N/A
- voice coil inductance L = 0,19 mH
- effective piston radiating area Sd = 93 cm2
- effective mechanical mass incl. air load mms = 12,8 g
- equivalent volume of compliance Vas = 11,5 l
- total Q factor Qts = 0,34 (Qms=8, Qes=0,36)
- voice coil diameter = 32 mm
- maximum peak linear excursion vibration xlin = +/- 4,5 mm
- mounting diameter d = 128 mm
- overall diameter d = 152 mm
- mounting depth (not countersunk) t = 80,5 mm
- mass m = 1,44 kg
