Wavecor SW223BD03 8¾" Balanced drive alu cone subwoofer 8 Ohm   The 8¾” transducer... more
Product information "Wavecor SW223BD03"

Wavecor SW223BD03 8¾" Balanced drive alu cone subwoofer 8 Ohm



The 8¾” transducer SW223BD03 was designed specifically for high performance compact subwoofer applications where sound quality and low distortion are the priorities.



Specifications

  • power handling (continuous/programme) = 200 W
  • frequency range = 25-1000 Hz
  • resonance frequency fs = 25 Hz
  • impedance R = 8 Ohm
  • sound pressure level SPL = 81 dB (2,83V; 1m)
  • DC resistance Re = 6 Ohm
  • force factor BL = 13,1 N/A
  • voice coil inductance L = 1,16 mH
  • effective piston radiating area Sd = 206 cm2
  • effective mechanical mass incl. air load mms = 89 g
  • equivalent volume of compliance Vas = 28 l
  • total Q factor Qts = 0,46 (Qms=10,2, Qes=0,48)
  • voice coil diameter = 51 mm
  • maximum peak linear excursion vibration xlin = +/- 11,7 mm
  • mounting diameter d = 192 mm
  • overall diameter d = 223,5 mm
  • mounting depth (not countersunk) t = 126 mm
  • mass m = 4,4 kg
