Peerless GBS-250F38CP01-04

€100.45 *

Prices incl. VAT plus shipping costs

Delivery time 1-3 Workdays

  • 810130
The Peerless GBS-250F38CP01-04 10" 4 ohm subwoofer provides a very slim profile that is capable... more
Product information "Peerless GBS-250F38CP01-04"

The Peerless GBS-250F38CP01-04 10" 4 ohm subwoofer provides a very slim profile that is capable of large excursion. A unique treater paper dome helps to provide room to move the motor assembly and spider further forward without sacrificing excursion or efficiency, which is an issue with many low profile driver designs. A highly optimized ferrite motor and unique suspension layout combine to give a cost effective solution in a previously unavailable package.

  • Just over 40mm mounting depth without sacrificing quality or performance
  • Amazing excursion capability for powerful bass response from shallow enclosures
  • Optimized ferrite motor design allows impressive efficiency from a low profile driver
  • Excellent choice for car audio systems where space is at a premium



Specifications

  • Nominal Diameter10"
  • Power Handling (RMS)200 Watts
  • Power Handling (max)400 Watts
  • Impedance4 ohms
  • Frequency Response50 to 2,000 Hz
  • Sensitivity85.8 dB 1W/1m
  • Voice Coil Diameter1.5"
  • Resonant Frequency (Fs)37.69 Hz
  • DC Resistance (Re)3.45 ohms
  • Voice Coil Inductance (Le)2.36 mH
  • Mechanical Q (Qms)5.62
  • Electromagnetic Q (Qes)0.49
  • Total Q (Qts)0.45
  • Compliance Equivalent Volume (Vas)0.84 ft.³
  • Mechanical Compliance of Suspension (Cms)0.157 mm/N
  • BL Product (BL)21.45 Tm
  • Diaphragm Mass Inc. Airload (Mms)103.4g
  • Maximum Linear Excursion (Xmax)6 mm
  • Surface Area of Cone (Sd)1,231 cm²
