Peerless SLS-315

€98.25 *

Prices incl. VAT plus shipping costs

Delivery time 1-3 Workdays

  • 830669
The Peerless SLS-315 12" Woofer P830669 combines high quality performance with an affordable... more
Product information "Peerless SLS-315"

The Peerless SLS-315 12" Woofer P830669 combines high quality performance with an affordable design. This 12 inch 8 ohm member of the SLS family features a rigid steel basket, a coated paper cone, and a ferrite magnet motor with aluminium shorting ring for improved distortion performance.



Specifications

Transducer Size     12 in
DC Resistance     5.6 Ω ±5.0%
Resonant Frequency     31.48 Hz 15%
Half Space Sensitivity @ 2.83V     89.85 dB ±1.01
Sensitivity @ 1W/1m     89.2 dB ±1.01
Rated Noise Power (IEC 268-5 18.1)     100 W
Effective Piston Area     522.8 cm2
Moving Mass     74.1 g
Motor Force Factor     11.88 T•m
Voice Coil Inner Diameter     38.44 mm
Gap Height     8 mm
Maximum Linear Excursion     8.3 mm
Ferrofluid Type
Minimum Impedance     6.95 Ω ±7.5%
Voice Coil Inductance     1.12 mH
Mechanical Q Factor     7.07
Electrical Q Factor     0.58
Total Q Factor     0.54
Ratio     58.51 fs/Qts
Test Spectrum Bandwidth (1300-20000 Hz)     30Hz - 2kHz 12 dB/Oct
Energy Bandwidth Product ((1/Qes)•fs)
Suspension Compliance     345 um/N
Effective Cone Diameter     25.8 cm
Motor Efficiency Factor     25.2 (T•m2)/Ω
Voice Coil Former Material     GSV GSV
Transducer Mass     3.24 Kg
Equivalent Volume     132.42 L
