Eton 7-312/C8/32 Hex

€247.38 *

Prices incl. VAT plus shipping costs

Delivery time approx. 5 working days

  • 1381332
7" Bass/midrange driver for multiple usage. Phase plug construction, 3-layer Hexacone sandwich... more
Product information "Eton 7-312/C8/32 Hex"

7" Bass/midrange driver for multiple usage. Phase plug construction, 3-layer Hexacone sandwich cone with a solid bass-base and uncolored sound performance.



Specifications

Nominal impedance Zn 8 Ω

DC resistance Re 6.7 Ω

Resonance frequency 1W fr 34 Hz

Resonance frequency TSP fr 35 Hz

Suspension compliance CMS 1.14 mm/N

Mechanical Q Qms 6.40

Electrical Q Qes 0.30

Total Q Qts 0.29

Mechanical resistance RMS 0.66 kg/s

Total moving mass (incl. air mass) MMD 17.3 g

Effective piston area SD 137 cm2

Voice coil inductance Le 0.90 mH

Force factor BLxl 8.8 Tm

Xmax electrical +/- 4.5 mm

Xmax mechanical +/- 8.8 mm

Equivalent volume VAS 30.0 dm3

Characteristic SPL 1W/1m 89 dB SPL

Rated power 80* W
