Product information "SB Acoustics SATORI MW16TX-4"
SB-Acoustics 6 1/2'' SATORI MW16TX-4
- Advanced TeXtreme® cone
- Vented aerodynamic cast aluminium chassis
- Soft low damping rubber surround
- Advanced BIMAX spider
- Powerful optimized low distortion neodymium motor system
- Extended copper sleeve on pole piece
- Non-conducting fiberglass voice coil former
- Vented pole piece and voice coil
- Light weight CCAW voice coil
- Long life silver lead wires
Specifications
- Nominal Impedance 4 Ω
- DC resistance, Re 3.4 Ω
- Voice coil inductance, Le 0.15 mH
- Effective piston area, Sd 119 cm2
- Voice coil diameter 36 mm
- Voice coil height 17 mm
- Air gap height 5 mm
- Linear coil travel (p-p) 12 mm
- Magnetic flux density 1.17 T
- Magnet weight 0.13 kg
- Net weight 1.01 kg
- Free air resonance, Fs 29 Hz
- Sensitivity (2.83V/1m) 90.5 dB
- Mechanical Q-factor, Qms 5.0
- Electrical Q-factor, Qes 0.29
- Total Q-factor, Qts 0.27
- Moving mass incl. air,Mms 12.6 g
- Force factor, Bl 5.2 Tm
- Equivalent volume, Vas 48 liters
- Compliance, Cms 2.39 mm/N
- Mechanical loss, Rms 0.46 kg/s
- Rated power handling* 60 W
