- Order number: hivi-ss1ii
-Heat-resistant, high damping dome membrane made of natural fiber -High-performance magnets,... more
Product information "HiVi SS1II"
-Heat-resistant, high damping dome membrane made of natural fiber
-High-performance magnets, antimagnetic shielded magnetic structure with great driving force
-High power handling voice coil with heat-resistant aluminum alloy former and aluminum voice coil wire coated with copper,
-Rigid M.I. front panel design-prevents unnecessary vibration
-Antimagnetic design-could be directly applied on home theatre system
-Recommended crossover frequency-above 2000 Hz
-Suitable for the tweeter of home hi-fi and home theater system
-It is upgraded from SS1, and could replace SS1 without changing crossover design
Specifications
| Nominal Impedance (Z)(Ω) : | 5 | |
| Resonance Frequency (Fs)(Hz) : | 1300 | |
| Nominal Power Handling (Pnom)(W) : | 15 | |
| Sensitivity (2.83v/1m)(dB) : | 91 | |
| Weight (M)(Kg) : | 0.6 | |
| VC Diameter (mm) : | 25 | |
| DC (Re)(Ω) : | 4.6 | |
| VC Layers : | 2 | |
| VC Former : | CCAW | |
| VC Frame : | ALuminum | |
| Magnet System : | Shielded | |
| Magnet Former : | Ferrite | |
| Recommended Crossover Frequency(Hz) : | >2000Hz | |
