Dayton Audio DCS305-4

€151.95 *

Prices incl. VAT plus shipping costs

Delivery time 7 Workdays

  • da-dcs305-4
The Dayton Audio Classic Series subwoofers offer solid value at lower price points. No... more
Product information "Dayton Audio DCS305-4"

The Dayton Audio Classic Series subwoofers offer solid value at lower price points. No compromises were made in the design, materials, or construction of these rugged 4-ohm powerhouses.



The Dayton Audio Classic Series subwoofers offer solid value at lower price points. No compromises were made in the design, materials, or construction of these rugged 4-ohm powerhouses. The drivers feature a vented pole piece with copper cap, bumped back plate for improved excursion capability, Kevlar reinforced cone with rubber half-roll surround, and a high-temperature 4-layer copper voice coil wound on a polyimide former.



Product Highlights

• Sturdy stamped steel frame
• Vented pole piece and bumped back plate
• Inductance-reducing copper pole piece cap
• Treated non-pressed paper/Kevlar cone with rubber surround
• 4-layer VC with polyimide former
• Great for home and automotive applications



Specifications

Impedance
4 ohms

Re
3.3 ohms

Le
2.06 mH @ 1 kHz

Fs
24.2 Hz

Qms
5.07

Qes
0.43

Qts
0.40

Mms
160g

Cms
0.27 mm/N

Sd
498.8 cm²

Vd
468.8 cm³

BL
13.7 Tm

Vas
92.3 liters

Xmax
9.3 mm

VC Diameter
65.5 mm

SPL
90.5 dB @ 2.83VW/1m

RMS Power Handling
250 watts

Usable Frequency Range (Hz)
23 - 200 Hz
