Scanspeak 15W/4531G00 5.25" Revelator midwoofers are famous for their Scanspeak Sliced Paper Cones, the slices are filled with damping glue. The effect is to reduce break-up nodes in the 6" cone, and give a midrange clarity and overall smooth frequency response which has made this top audiophile range uniquely successful.
- Low Loss linear suspension
- Large ferrite magnet system
- High output.
Specifications
power handling (continuous/programme) = 60 W
frequency range = 30-6000 Hz
resonance frequency fs = 40 Hz
impedance R = 4 Ohm
sound pressure level SPL = 87 dB (2,83V; 1m)
DC resistance Re = 3,4 Ohm
force factor BL = 5,7 N/A
voice coil inductance L = 0,25 mH
effective piston radiating area Sd = 95 cm2
effective mechanical mass incl. air load mms = 13 g
equivalent volume of compliance Vas = 15,8 l
total Q factor Qts = 0,32 (Qms=4,6, Qes=0,34)
voice coil diameter = 38 mm
maximum peak linear excursion vibration xlin = +/- 6,5 mm
