Gradient AXP-06

Gradient AXP-06
€68.10 *

Prices incl. VAT plus shipping costs

Delivery time 7-14 Workdays

  • 1381663
Gradient Axis AXP-06  High Power Midrange Loudspeaker 6" loudspeaker driver... more
Product information "Gradient AXP-06"

Gradient Axis AXP-06 High Power Midrange Loudspeaker

  • 6" loudspeaker driver
  • high-efficiency performance high sensitivity
  • lightweight, reinforced paper cone for excellent detail
  • heavy-duty 6-hole cast frame
  • gold terminals



Specifications

  • Frequency range Hz
  • Nominal impedance 8 Ω
  • Cone Coated paper
  • Surround material Tissue
  • Basket material Aluminium
  • Magnet material Ferrite
  • Voice coil diameter 25 mm
  • Voice coil former capton
  • Outside diameter 180 mm
  • Build in hole diameter 146 mm
  • Build in depth 82 mm
  • SPL (1W/1M) 93,5
  • fs 57 Hz
  • VAS 26,2 L
  • QMS 3,87 –
  • QES 0,35 –
  • QTS 0,32 –
  • Re 6,7 Ω
  • Sd 145 cm2
  • Cms 0,89 247 μm/N
  • Mms 8,9 g
  • LE 0,15 VC/mH
  • BL 7,74 (NA) (F/I)
