Fostex F120A

Fostex F120A
€349.00 *

Prices incl. VAT plus shipping costs

Delivery time approx. 5 working days

  • fo-10719
120mm (5 in) cone type full range 8 ohm impedance fo to 20kHz frequency response 89dB... more
Product information "Fostex F120A"
  • 120mm (5 in) cone type full range
  • 8 ohm impedance
  • fo to 20kHz frequency response
  • 89dB sensitivity at 1W/1m (3.3ft)
  • 2.0kg (4.409 lb) net weight



Technical Data:

  • power handling (continuous/programme) = 10/30 W
  • frequency range = 80-20000 Hz
  • resonance frequency fs = 70 Hz
  • impedance R = 8 Ohm
  • sound pressure level SPL = 89 dB (2,83V; 1m)
  • DC resistance Re = 7,3 Ohm
  • effective piston radiating area Sd = 66,5 cm2
  • effective mechanical mass incl. air load mms = 5,3 g
  • equivalent volume of compliance Vas = 8,21 l
  • total Q factor Qts = 0,45 (Qms=8,4, Qes=0,47)
  • maximum peak linear excursion vibration xlin = +/- 2 mm
  • mounting diameter d = 126 mm
  • overall diameter d = 123 mm
  • mounting depth (not countersunk) t = 62,5 mm
