- Order number: SW10527
Markaudio produces fullranges that play almost without correction. Here we have chosen an Alpair 7, complemented with 2 Wavecor SW178WA01 subwoofers connected in parallel. The crossover frequency was chosen so that on the one hand the fullrange is not deflected too far (the resulting Doppler effect causes frequency shifts) on the other hand you don't have a decay in sound. The latter perceive critical ears if the middle frequency range is split between different speakers. As an optimal solution, the crossover frequency is around 300 Hz. Such systems are also called FAST (Fullrange And Subwoofer Technology). FAST refers to the group of transducers with fullrange speakers, where the fullrange concentrates on the middle and upper frequency ranges, while at the bottom it is supported by a bass speaker.
The crossover consists of a high and a low pass 2nd order (12 dB / octave). Parallel to the two woofers, a absorption circuit acts to suppress their resonances. In series with the broadband, a blocking circuit levels the frequency response.
The frequency response is reasonably linear at 20 degrees; the decay spectrum is good for a fullrange.
The magazine Klang + Ton certifies in their test then also: "So and not otherwise we imagine a modern fast system"
An excerpt from the Klang + Ton Hörtest
... "As complete as it measures itself, the Gila also sounds great deep, clean and firm in the bass, even at high levels, even at ultra-low, electronically generated impulses. neutrality and a convincing spatial image go hand in hand, coupled with a high-pitched reproduction, which can be adjusted depending on the angle of incidence between soft and crystal clear-biting, it is never too intrusive, because the The Gila is a FAST system that can compete in terms of technical sovereignty with any "normal" box - plus the better spaciousness of the broadband and the extra cymbal bass.All right: everything done right 'just better!'
Conclusion in sound + sound
"The Gila is not extremely cheap, but has the intrinsic values that distinguish an excellent speaker from the only good ones."
The kit contains,
- Mark Audio Alpair 7 Generation 3 Grey
- 2x Wavecor Subwoofer SW178WA01, 8 Ohm
- 2x Bassreflex tube HP70, 68x160 mm
- Dampingmaterials (Bondum 800, Sonofil White)
- Goldplated speakerterminals
- 3m speakercable 2x1,5 mm2, transparent
- Panhead screws 4x20 schwarz, 8 pcs
- Crossover kit
- Buildingplans for this speakerkit
(no wood panels included)
