- Order number: DTAC2u20J630V
ClarityCap DTAC 2.20uF 630Vdc Voltage rating: 630 Vdc Tolerance: +/- 5%... more
Product information "2.20uF 630V 5% ClarityCap DTAC"
ClarityCap DTAC 2.20uF 630Vdc
Voltage rating: 630 Vdc
Tolerance: +/- 5%
Diamter: min/max 36/42mm ,typical 38
The DTAC range of capacitors was designed with one aim in mind, to produce a capacitor with the lowest resistance possible.
This is achieved by winding from with a narrow polypropylene film with a special spray and heat treatment process which all contribute to the exceptional performance of this capacitor. Combined with hand soldered M8 tinned copper terminals ensure that the ESR is greatly reduced when compared to the traditional axial leaded components.
